Application:
|
Radiator / Coolant / Air Hose
|
|
Reinforcement:
|
Polyester
|
|
Temperature:
|
-60°C to +180°C
|
|
Standard:
|
SAE J20
|
【product description】Silicone hoses are designed to connect metal pipe work and components in systems using water and ethylene glycol based coolants. All our t-piece hoses have a 25mm outlet ideal for creating an outlet in a charge air line or intake system. Used to connect dump valves, breather take off, water take off and much more.
Silicone hose is a extremely flexible compared to rubber, with the ability to maintain this flexibility over the lifespan of its use. Under some conditions rubber hoses are at risk of splitting, hardening, or dry rot, which is why silicone hoses are the choice for many trucks, buses, performance cars, and many other vehicle and industrial applications.
We increase the number of plys and wall thickness of our tee piece hoses as the diameter increases, this is because we want all our range capable of carrying fluid and air at very high pressures. So if you’re building a racing vehicle, adding turbochargers or superchargers, our silicone hose is the way to go.
|
BRAND
|
Auto Silicone Hoses
|
|
SELECT ANGLE
|
T Piece
|
|
HAZARDOUS GOODS
|
No
|
|
ROHS COMPLIANT
|
Yes
|
|
SELECT LENGTH
|
100mm
|
|
MAX LENGTH
|
100mm / 4 Inch
|
|
WALL THICKNESS
|
4.5mm / 5.5mm
|
|
OUTLET SIZE
|
25mm
|
|
PART NUMBER
|
STP-ASH
|
|
TEMPERATURE RATING
|
-60°C to +180°C
|
|
APPLICATION
|
Engine coolant systems, Radiator hose, Turbo, Dump Valves, Breather Take Offs, Water Take Off
|
|
SAFETY FACTOR
|
3 x Working Pressure
|
|
HOSE GRADE
|
SAE J20
|
|
HOSE CONSTRUCTION
|
Polyester Reinforcement / VMQ Silicone Rubber
|
|
SELECT MATERIAL
|
Silicone Polyester Reinforced
|
|
MANUFACTURER
|
Auto Silicone Hoses
|
|
RETURN PERIOD
|
30 days
|
